| Brand Name: | ZhaoGuang |
| Model Number: | ZG-FQ |
| MOQ: | 1 set |
| Payment Terms: | T/T |
| Supply Ability: | 300 |
| Model | 1575 | 2000 | 2200 | 2600 | 2900 |
| Max.width of jumbo roll(mm) | 1750 | 1950 | 2150 | 2550 | 2850 |
| Diameter of jumbo roll(mm) | ≤1500mm | ||||
| Finished products diameter(mm) | 1100 | ||||
| Finished product width(mm) | adjustable | ||||
| Backstand | 1-3sets(should be ordered) | ||||
| Air shaft | 1-4pcs(should be ordered) | ||||
| Calendering unit | Steel to rubber,steel to steel(should be ordered) | ||||
| Transmission system | Chain and chain wheel or separating motor driving(should be ordered) | ||||
| Power | 5.5-11Kw,380V,50Hz(base on the model) | ||||
| Air pressure | 0.8Mpa(user supplied) | ||||
| Machine size(mm) | 6200*2600*1800-6200*4000*1800(L*W*H,base on model) | ||||
