| Brand Name: | ZhaoGuang |
| Model Number: | ZGFJ2600 |
| MOQ: | 1 set |
| Payment Terms: | T/T |
| Supply Ability: | 300 |
| MODLE | 2600 | 3000 |
| Max.Jumbo roll width(mm) | 2550 | 2950 |
| Capacity | 5 tons/day | 7 tons/day |
| Finished product diameter(mm) | Ф70-300 | |
| Finished product core inner diameter(mm) | Ф35-80 | |
| Jumbo roll diameter(mm) | ≤Ф1500(other size should be ordered) | |
| Jumbo roll core inner diameter(mm) | Ф76.2(other size should be ordered) | |
| Perforating size(mm) | 110mm(other size should be ordered,4PCS spiral perforating blade) | |
| Machine speed | 22m/min | |
| Parameter setting | MITSUBISHI touch screen | |
| PLC control | MITSUBISHI PLC | |
| backstand | 1-6sets(should be ordered) | |
| Air pressure | 0.8Mpa(user supply) | |
| Power | 15/25Kw,380V,50Hz(base on the model) | |
| Option | ||
| Embossing unit | Single,double embossing/steel to steel/steel to rubber/steel to paper(should be ordered) | |
| Backstand | 1-6 sets(should be ordered) | |
| Jumbo roll loading | Pneumatic loader/elevator(should be ordered) | |
| Lamination unit | Point to point or glue for nest(should be ordered) | |
| Core or coreless unit | Should be ordered | |
| Core winding machine | Should be ordered | |
| Automatic core feeding device | 300-600PCS storage(should be ordered) | |
| Edge embossing unit | Air bag type(should be ordered) | |
| Calendering unit | Steel to steel/steel to rubber(should be ordered) | |
| Accumulator | 110-210rolls type(should be ordered) | |
| Log saw cutter | 2 lanes log saw cutter(should be ordered) | |
